Texas Instruments DRV8312DDW

DRV8312DDW
Part No.:
DRV8312DDW
Manufacturer:
Texas Instruments
Category:
PMIC - Full, Half-Bridge Drivers
Package:
44-TSSOP (0.244, 6.20mm Width) Exposed Pad
Datasheet:
LINKCOST DEVICE SOLUTION LIMITEDDRV8312DDW.pdf
Description:
IC BRIDGE DRIVER PAR 44HTSSOP
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Product Comparison
  • Related Categories
Packaging:
Tube
Series:
-
ProductStatus:
Active
OutputConfiguration:
Half Bridge (3)
Applications:
DC Motors, General Purpose
Interface:
PWM
LoadType:
Inductive
Technology:
Power MOSFET
RdsOn(Typ):
80mOhm LS, 80mOhm HS
Current-Output/Channel:
3.5A
Current-PeakOutput:
6.5A
Voltage-Supply:
10.8V ~ 13.2V
Voltage-Load:
0V ~ 52.5V
OperatingTemperature:
-40°C ~ 150°C (TJ)
Features:
Bootstrap Circuit, Status Flag
FaultProtection:
Current Limiting, Over Temperature, Short Circuit, UVLO
MountingType:
Surface Mount
Category:
PMIC - Full, Half-Bridge Drivers
Datasheet:
LINKCOST DEVICE SOLUTION LIMITEDDRV8312DDW.pdf
