Diodes Incorporated AH3564Q-SA-7

AH3564Q-SA-7
Part No.:
AH3564Q-SA-7
Manufacturer:
Diodes Incorporated
Category:
Magnetic Sensors - Switches (Solid State)
Package:
SOT-23-3
Datasheet:
LINKCOST DEVICE SOLUTION LIMITEDAH3564Q-SA-7.pdf
Description:
MAG SWITCH OMNIPOLAR SOT23 T&R
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Product Comparison
  • Related Categories
Packaging:
Tape & Reel (TR),Cut Tape (CT)
Series:
Automotive, AEC-Q100
ProductStatus:
Active
Function:
Omnipolar Switch
Technology:
Hall Effect
Polarization:
North Pole, South Pole
SensingRange:
±6mT Trip, ±1mT Release
TestCondition:
-40°C ~ 125°C
Voltage-Supply:
3V ~ 28V
Current-Supply(Max):
4mA
Current-Output(Max):
55mA
OutputType:
Open Drain
Features:
Temperature Compensated
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
Category:
Magnetic Sensors - Switches (Solid State)
Datasheet:
LINKCOST DEVICE SOLUTION LIMITEDAH3564Q-SA-7.pdf
