Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
IRF7233MOSFET P-CH 12V 9.5A 8SO |
3,373 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 12 V | 9.5A (Ta) | 2.5V, 4.5V | 20mOhm @ 9.5A, 4.5V | 600mV @ 250µA (Min) | 74 nC @ 5 V | ±12V | 6000 pF @ 10 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
![]() |
IRFI9640GMOSFET P-CH 200V 6.1A TO220-3 |
3,119 | - |
|
![]() Datasheet |
Tube | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 200 V | 6.1A (Tc) | 10V | 500mOhm @ 3.7A, 10V | 4V @ 250µA | 44 nC @ 10 V | ±20V | 1200 pF @ 25 V | - | 40W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
![]() |
IRFI9634GMOSFET P-CH 250V 4.1A TO220-3 |
3,475 | - |
|
Tube | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 250 V | 4.1A (Tc) | 10V | 1Ohm @ 2.5A, 10V | 4V @ 250µA | 38 nC @ 10 V | ±20V | 680 pF @ 25 V | - | 35W (Tc) | -55°C ~ 150°C (TJ) | Through Hole | |
![]() |
IRF5210LMOSFET P-CH 100V 40A TO262 |
2,020 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 100 V | 40A (Tc) | 10V | 60mOhm @ 24A, 10V | 4V @ 250µA | 180 nC @ 10 V | ±20V | 2700 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF5305LMOSFET P-CH 55V 31A TO262 |
3,674 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 55 V | 31A (Tc) | 10V | 60mOhm @ 16A, 10V | 4V @ 250µA | 63 nC @ 10 V | ±20V | 1200 pF @ 25 V | - | 3.8W (Ta), 110W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF6215LMOSFET P-CH 150V 13A TO262 |
2,311 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 150 V | 13A (Tc) | 10V | 290mOhm @ 6.6A, 10V | 4V @ 250µA | 66 nC @ 10 V | ±20V | 860 pF @ 25 V | - | 3.8W (Ta), 110W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF9520NLMOSFET P-CH 100V 6.8A TO262 |
2,530 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 100 V | 6.8A (Tc) | 10V | 480mOhm @ 4A, 10V | 4V @ 250µA | 27 nC @ 10 V | ±20V | 350 pF @ 25 V | - | 3.8W (Ta), 48W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF9530NLMOSFET P-CH 100V 14A TO262 |
3,719 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 100 V | 14A (Tc) | 10V | 200mOhm @ 8.4A, 10V | 4V @ 250µA | 58 nC @ 10 V | ±20V | 760 pF @ 25 V | - | 3.8W (Ta), 79W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF9540NLMOSFET P-CH 100V 23A TO262 |
3,004 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 100 V | 23A (Tc) | 10V | 117mOhm @ 11A, 10V | 4V @ 250µA | 97 nC @ 10 V | ±20V | 1300 pF @ 25 V | - | 3.8W (Ta), 140W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
![]() |
IRF9Z24NLMOSFET P-CH 55V 12A TO262 |
3,866 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 55 V | 12A (Tc) | 10V | 175mOhm @ 7.2A, 10V | 4V @ 250µA | 19 nC @ 10 V | ±20V | 350 pF @ 25 V | - | 3.8W (Ta), 45W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF9Z34NLMOSFET P-CH 55V 19A TO262 |
2,314 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 55 V | 19A (Tc) | 10V | 100mOhm @ 10A, 10V | 4V @ 250µA | 35 nC @ 10 V | ±20V | 620 pF @ 25 V | - | 3.8W (Ta), 68W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF1010ESTRRMOSFET N-CH 60V 84A D2PAK |
3,975 | - |
|
![]() Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 84A (Tc) | 10V | 12mOhm @ 50A, 10V | 4V @ 250µA | 130 nC @ 10 V | ±20V | 3210 pF @ 25 V | - | 200W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
![]() |
IRF1010NSTRLMOSFET N-CH 55V 85A D2PAK |
2,930 | - |
|
![]() Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 85A (Tc) | 10V | 11mOhm @ 43A, 10V | 4V @ 250µA | 120 nC @ 10 V | ±20V | 3210 pF @ 25 V | - | 180W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
![]() |
IRF1010NSTRRMOSFET N-CH 55V 85A D2PAK |
2,726 | - |
|
![]() Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 85A (Tc) | 10V | 11mOhm @ 43A, 10V | 4V @ 250µA | 120 nC @ 10 V | ±20V | 3210 pF @ 25 V | - | 180W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
![]() |
IRF1104LMOSFET N-CH 40V 100A TO262 |
2,840 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 10V | 9mOhm @ 60A, 10V | 4V @ 250µA | 93 nC @ 10 V | ±20V | 2900 pF @ 25 V | - | 2.4W (Ta), 170W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
![]() |
IRF1104SMOSFET N-CH 40V 100A D2PAK |
2,020 | - |
|
![]() Datasheet |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 10V | 9mOhm @ 60A, 10V | 4V @ 250µA | 93 nC @ 10 V | ±20V | 2900 pF @ 25 V | - | 2.4W (Ta), 170W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
![]() |
IRF1104STRLMOSFET N-CH 40V 100A D2PAK |
3,582 | - |
|
![]() Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 10V | 9mOhm @ 60A, 10V | 4V @ 250µA | 93 nC @ 10 V | ±20V | 2900 pF @ 25 V | - | 2.4W (Ta), 170W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
![]() |
IRF1104STRRMOSFET N-CH 40V 100A D2PAK |
3,849 | - |
|
![]() Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 10V | 9mOhm @ 60A, 10V | 4V @ 250µA | 93 nC @ 10 V | ±20V | 2900 pF @ 25 V | - | 2.4W (Ta), 170W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
![]() |
IRF1310NSTRRMOSFET N-CH 100V 42A D2PAK |
2,499 | - |
|
![]() Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 42A (Tc) | 10V | 36mOhm @ 22A, 10V | 4V @ 250µA | 110 nC @ 10 V | ±20V | 1900 pF @ 25 V | - | 3.8W (Ta), 160W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
![]() |
IRF1404STRRMOSFET N-CH 40V 162A D2PAK |
2,950 | - |
|
![]() Datasheet |
Tape & Reel (TR) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 162A (Tc) | 10V | 4mOhm @ 95A, 10V | 4V @ 250µA | 200 nC @ 10 V | ±20V | 7360 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
