Optoisolators - Logic Output
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Inputs-Side1/Side2 | Voltage-Isolation | CommonModeTransientImmunity(Min) | InputType | OutputType | Current-Output/Channel | DataRate | PropagationDelaytpLH/tpHL(Max) | Rise/FallTime(Typ) | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | Voltage-Supply | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TLP250H(TP5,F)OPTOCOUPLER 8DIP SMD GW |
2,110 | - |
|
Tape & Reel (TR) | - | Active | 1 | 1/0 | 3750Vrms | 40kV/µs | DC | Push-Pull, Totem Pole | 2 A | - | 500ns, 500ns | 50ns, 50ns | 1.57V | 20mA | 10V ~ 30V | -40°C ~ 125°C | Surface Mount | |
|
TLP250HF(TP4,F)OPTOCOUPLER 8DIP |
2,298 | - |
|
Tape & Reel (TR) | - | Active | 1 | 1/0 | 3750Vrms | 40kV/µs | DC | Push-Pull, Totem Pole | 2 A | - | 500ns, 500ns | 50ns, 50ns | 1.57V | 5mA | 10V ~ 30V | -40°C ~ 125°C | Surface Mount | |
.JPG)
|
TLP2395(TPL,EOPTOISOLATOR PSH PULL 6MFSOP-5 |
3,161 | - |
|
Tape & Reel (TR) | - | Active | 1 | 1/0 | 3750Vrms | 20kV/µs | DC | Push-Pull, Totem Pole | 25 mA | 5Mbps | 250ns, 250ns | 15ns, 12ns | 1.5V | 20mA | 3V ~ 20V | -40°C ~ 125°C | Surface Mount | |
|
|
TLP250HF(LF4,F)OPTOCOUPLER 8DIP |
2,910 | - |
|
Tube | - | Active | 1 | 1/0 | 3750Vrms | 40kV/µs | DC | Push-Pull, Totem Pole | 2 A | - | 500ns, 500ns | 50ns, 50ns | 1.57V | 5mA | 10V ~ 30V | -40°C ~ 125°C | Surface Mount | |
|
|
TLP2395(EOPTOISOLATOR PSH PULL 6MFSOP-5 |
3,067 | - |
|
Tube | - | Active | 1 | 1/0 | 3750Vrms | 20kV/µs | DC | Push-Pull, Totem Pole | 25 mA | 5Mbps | 250ns, 250ns | 15ns, 12ns | 1.5V | 20mA | 3V ~ 20V | -40°C ~ 125°C | Surface Mount | |
|
TLP2768A(D4-TP,EOPTOISOLATOR SO6 |
2,604 | - |
|
Tape & Reel (TR) | - | Active | 1 | 1/0 | 5000Vrms | 20kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 20MBd | 60ns, 60ns | 30ns, 30ns | 1.55V | 25mA | 2.7V ~ 5.5V | -40°C ~ 125°C | Surface Mount | |
|
|
TLP2745(EOPTOCOUPLER SO6 |
3,819 | - |
|
Tube | - | Active | 1 | 1/0 | 5000Vrms | 30kV/µs | DC | Push-Pull, Totem Pole | 50 mA | - | 120ns, 120ns | 3ns, 3ns | 1.55V | 15mA | 4.5V ~ 30V | -40°C ~ 110°C | Surface Mount | |
|
|
TLP2631(LF1,F)PHOTOCOUPLER |
3,282 | - |
|
Tube | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
TLP2630(LF1,F)PHOTOCOUPLER |
2,953 | - |
|
Tube | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
TLP2768A(D4,EOPTOISOLATOR SO6 |
2,920 | - |
|
Tube | - | Active | 1 | 1/0 | 5000Vrms | 20kV/µs | DC | Open Collector, Schottky Clamped | 25 mA | 20MBd | 60ns, 60ns | 30ns, 30ns | 1.55V | 25mA | 2.7V ~ 5.5V | -40°C ~ 125°C | Surface Mount | |
|
|
TLPN137(S)IC COUPLER HS LOGIC |
3,742 | - |
|
Tube | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
TLP250HF(D4,F)OPTOCOUPLER 8DIP |
3,947 | - |
|
Tube | - | Active | 1 | 1/0 | 3750Vrms | 40kV/µs | DC | Push-Pull, Totem Pole | 2 A | - | 500ns, 500ns | 50ns, 50ns | 1.57V | 5mA | 10V ~ 30V | -40°C ~ 125°C | Through Hole | |
|
|
TLP2200(LF2,F)PHOTOCOUPLER |
2,512 | - |
|
Tube | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
TLP5702(D4-TP,EOPTOCOUPLER DRIVER SO6 |
2,719 | - |
|
Tape & Reel (TR) | - | Active | 1 | 1/0 | 5000Vrms | 30kV/µs | DC | Photo IC | 50 mA | 5Mbps | 200ns, 250ns | 3ns, 3ns | 1.55V | 20mA | 15V ~ 30V | -40°C ~ 110°C | Surface Mount | |
|
|
TLP2118(TP,F)PHOTOCOUPLER SO8 |
2,059 | - |
|
Tape & Reel (TR) | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
TLP2095(TPL,F)PHOTOCOUPLER MFSOP |
2,137 | - |
|
Tape & Reel (TR) | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
TLP2631(TP5,F)PHOTOCOUPLER |
2,506 | - |
|
Tape & Reel (TR) | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
TLPN137(D4,S)IC COUPLER HS LOGIC |
2,122 | - |
|
Tube | * | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
TLP5702(D4,EOPTOCOUPLER DRIVER SO6 |
3,092 | - |
|
Tube | - | Active | 1 | 1/0 | 5000Vrms | 30kV/µs | DC | Photo IC | 50 mA | 5Mbps | 200ns, 250ns | 3ns, 3ns | 1.55V | 20mA | 15V ~ 30V | -40°C ~ 110°C | Surface Mount | |
|
|
TLP2398(EOPTOISOLATOR PSH PULL 6MFSOP-5 |
3,093 | - |
|
Tape & Reel (TR) | - | Active | 1 | 1/0 | 3750Vrms | 20kV/µs | DC | Push-Pull, Totem Pole | 25 mA | 5Mbps | 250ns, 250ns | 15ns, 12ns | 1.5V | 20mA | 3V ~ 20V | -40°C ~ 125°C | Surface Mount |
